vitapur Pro Soft VWS296GR - Product View and Parts Identification

2
Parts Location:
WhenyouopenyourCabinetSoftenercarton,youwillfindthecomponentslocatedintheareasshownbelow:
Bypass Assembly:
• Wrenchforvalveneck
• Onebypassgasket
• Completebypasswith
 connectorsandclips
• Inletvalveadapter
• PowerAdapter
Inside Brine Tank:
•Two½”draintubingwithtwoclamps:
valvedrainpipe4.1m/13.5ftlong
Brinetankoverflowhose2.1m/6ftlong
LCD display connector (to be connected to top cover)
Connect
3
/
8
“ white tubing from valve to
brine tank via quick connect elbow
Power adapter connection to valve
• LCDdisplaywire
(Tobeconnected
tosoftenerhead
connectionbelow)
Top View:
Side View:
Inside Top Cover:
