vitapur Pro Soft VWS296GR - Drain Line Connection; Overflow Line Connection

6
Theclipsconnectingthebypassassemblytothevalveareinsertedinthedownwarddirectionwhenthe
inletandoutletportsarefacingdownwards.Thelockingclipsareinsertedintheupwardsdirectionfrom
thebottomwhentheinletandoutletportsareupwards.
When the bypass assembly is in service mode the soft water is delivered to the building. During
regenerationcyclehardwaterisdeliveredtothewatersoftenerwhilealsoprovidinghardwatertothe
buildingdistributionsystem.
bypass assembly wiTh inleT and ouTleT
porTs faCing upwards)
bypass assembly wiTh inleT and ouTleT
porTs faCing downwards)
Locking Clips
insTallaTion insTruCTions
Assembling the Water Softener:
CAUTION: When maneuvering
the resin tank into the cabinet
do not attempt to lift the resin
tank by the top cover.
Rotate the valve and resin tank on the
ground to maneuver it into place for
the installation.
Fig. N Fig. O
Locking Clips
6.
7.
8.
Pleasecheckthattheflow
metercableisconnectedon
thevalveoutletport.
