vitapur Pro Soft VWS296GR - Valve Adapter and Bypass Assembly

3
Tools Required:
• Flatheadscrewdriver
• Pliers
• TapeMeasure
• PipeCutter
• PropaneTorch
ValVe adapTer and bypass assembly
The¾”valveadaptersthatconnectthebypassassemblytovalveareshownintheFigA&Fig.B.
Theinlet&outletadaptersinFigBareinstalledonthewatersoftenervalveatthemanufacturingfacility.
These valves allow you to connect the bypass assembly with the inlet and outlet ports in the downward
directionFig.D.
Fig.Ashowsalongerinletwateradapter.Thismeansthattheshorterinletadapterhastoberemovedand
replacedwiththelongerinletadapterifyouwantthebypassassemblywiththeinletandoutletportsfacing
upwards.(Fig.C)
Fig.C.Thelongerinletadapterisintheboxcontainingthebypassassembly,poweradapterandwrenchfor
neckspacerremoval(ifneeded).
Additional Installation Materials Not Supplied:
• ¾”Copperadapter,or½”to¾”copperadapter
• ¾”Pexpipeadapteror½”to¾”pexpipeadapter
• Leadfreesolder&Flux
• Emeryclothorsteelwool
• TeflonTape
Outlet Adapter
Outlet Port Outlet PortInlet Port Inlet Port
Outlet AdapterInlet Adapter Inlet Adapter
Fig. A
Fig. C
Fig. B
Fig. D
1.
