MGW Ace Encoder HEVC Encoding and Streaming Appliance
User Manual, Version 2.1 24
• Stopped – Orange. The settings for this channel are
configured, but the channel has not been activated by
the user.
• Playing – Green. The channel is being encoded, and
streaming without any known errors.
• Error – Red. The channel has encountered an error.
Detailed information can be obtained from the channel's
event log.
Play/Stop
Analog Settings
Event Log
Live Preview
Displays the channel status, allows you to change it, as well
as preview the channel and view its related events.
Play/Stop - allows to start or stop a channel.
Analog Settings - Brings up a window in which the
following Analog Audio/Video parameters can be set on-the-
fly: Audio Gain, Hue, Brightness, Contrast, and
Saturation settings are accessible only when an analog
source is used.
Event Log - provides quick access to the event log of the
displayed channel.
Live Preview – provides quick access to the Live Preview
of the displayed channel.
Displays the channel name as set by the user.
• Multicast IP
• Unicast IP
• URL
Displays the target IP address, port number or the URL
string.
Indicates if KLV metadata is being inserted into the stream
(enabled or disabled).
