MGW Ace Encoder HEVC Encoding and Streaming Appliance
User Manual, Version 2.1 26
To view the dashboard parameters:
1. From the main menu, select Dashboard. The following parameters are displayed:
NOTE:
The Dashboard page automatically polls the appliance hardware for the latest status of channels, streams and
sources every 30 seconds. You may also manually refresh the Dashboard page (by either pressing the "F5" key
on your keyboard or re-clicking Dashboard), to obtain instantly the current state of the system whenever you
configure any of the following parameters: streaming/ management interfaces, traffic, or rear panel connections.
IP Address – Displays the Network Interface #1 IP address.
Subnet Mask – Displays the Network Interface #1 subnet mask
address.
Default Gateway – Displays the Network Interface #1 Default Gateway
address.
IP Address – Displays the Network Interface #2 IP address.
Subnet Mask – Displays the Network Interface #2 subnet mask
address.
Default Gateway – Displays the Network Interface #2 Default Gateway
address.
Outgoing Streams – Actual stream Bandwidth from both Network Cards.
Serial TX – Bytes transmitted from the serial port. (KLV - Live)
Serial RX - Bytes received from the serial port. (CoT - Live)
Zixi Channels Statistics - When a Zixi channel is started, the info button
provides detailed Zixi statistics information (see Zixi Statistics
Information section below)
Displays the source inputs of the platform. The following is the
indications of the source current connection state:
Green – connected
White – not connected.
• Temperature – Displays the platform's internal temperature in
Celsius. The value turns to red when out-of range.
• Up Time – Displays up-time since the last system boot.
• Date/Time – Display the platform date and time.
• NTP – An indication LED for status of network time server.
Green - Synchronizing with NTP server.
