MGW Ace Encoder HEVC Encoding and Streaming Appliance
User Manual, Version 2.1 50
To set the network interface (see figure above):
Two network interfaces are available. Each one can be used for either management and/or
streaming. For easier management of the system, Ethernet Port 2 can be configured in DHCP
mode. If DHCP mode is selected, Ethernet Port 2 will obtain the IP address automatically from the
DHCP server and the DNS server will also be populated automatically.
Select the Ethernet Port used for management (Ethernet Port 1, 2 or
1&2)
IP Address/IPv6
Address/Prefix
Enter a static IP address and a prefix address in case IPv6 is used.
Enter the subnet mask address.
Enter the gateway address
Enable DHCP (Ethernet
Port 2)
Select this box to enable automatic retrieval of IP address and DNS
server information from the DHCP server.
Optional field - required if a domain name is used instead of an IP
address (RTMP protocol).
Optional field - required if a domain name is used instead of an IP
address (RTMP protocol).
To control MGW Ace Encoder over HTTPS API:
Select “Enable HTTP API” check box to enable system control and status over the HTTPS REST
API.
The API documentation can be accessed through the question mark link.
To control MGW Ace Encoder over Wi-Fi:
Using the optional VITEC USB Wi-Fi Adapter (14324), it is possible to control MGW Ace Encoder
over Wi-Fi. On the field, it allows an easier control of the unit over a smartphone, tablet or laptop.
By default, Wi-Fi control is disabled for security reasons. Wi-Fi must be enabled once prior being
able to control the unit over Wi-Fi.
To enable Wi-Fi control:
1. Connect the VITEC USB Wi-Fi Adapter to the front panel USB port of MGW Ace Encoder
2. Select “Enable Wi-Fi control” checkbox in the Services section
3. Enter the Wi-Fi network SSID (Wi-Fi network name).
