7. TECHNICAL P A R A M E T E R S
Continued from previous page
L T E modul
UMTS parameters PS bit rate 384 kbps (DL) / 384 kbps (UL)
CS bit rate 64 kbps (DL) / 64 kbps (UL)
W-C D MA FDD standard
GPRS/EDGE parameters Bit rate 237 kbps (DL) / 59,2 kbps (UL)
GPRS multislot class 10, CS 1 to 4
EDGE multislot class 12, CS 1 to 4,
MCS 1 to 9
Supported GPRS/EDGE
power classes
EGSM 900: Class 4 (33 dBm)
GSM 1800/1900: Class 1 (30 dBm)
EDGE 900: Class E2 (27 dBm)
EDGE 1800/1900: Class E2 (26 dBm)
Supported channels GSM/GPRS/EDGE: 900/1800/1900 MHz
UMTS/HSDPA/HSUPA/HSPA+: 900/2100 MHz
L T E : 800/900/1800/2100/2600 Mhz
T a b l e 13: T e c h n i c a l parameters of module
7.3 T e c h n i c a l parameters of processor
32b ARM mikroprocesor
Memory 512 Mb DDR SDRAM
128 Mb FLASH
1 Mb MRAM
Interface Serial interface RS232
Ethernet interface 10/100 Mbit/s
USB 2.0 interface
T a b l e 14: T e c h n i c a l parameters of processor
7.4 T e c h n i c a l parameters I/O port
32b ARM mikroprocesor
Input/Output Binary input
Binary output
R e e d contact with trigger level 1,3 up to 1,4 V
100 mA / max. 30 V
T a b l e 15: T e c h n i c a l parameters I/O port
7.5 T e c h n i c a l parameters of e x p a n s i o n port
T e c h n i c a l parameters of the e x p a n s i o n ports are specified in separate manuals fo r e x p a n -
sion ports.
26
