VIVOTEK
User's Manual - 105
settings on page 91.
A green bar indicates that even though motions have been detected, the event has not been triggered
because the image variations still fall under the dened threshold.
If you want to congure other motion detection settings for a different time period within a day, please
click Prole to open the Motion Detection Prole Settings page as shown below. A total of three motion
detection windows can be congured on this page as well.
Please follow the steps beolw to set up a prole and additional motion detectio windows in it:
1. Create a new motion detection window.
2. Check Enable this prole.
3. Select the applicable span of time in the Schedule mode. Please manually enter a time range if you
choose Schedule mode.
4. Click Save to enable the settings and click Close to exit the page.
This motion detection window will also be displayed on the Event Settings page. You can go to Event
> Event settings > Trigger to choose it as a trigger source. Please refer to page 109 for detailed
information.
Percentage = 30%
Video(TCP-AV)
2010/12/10 17:08:56
corridor
