Vivotek FD8166 - Physical Description and Installation; Physical Description

VIVOTEK
6 - User's Manual
Physical Description
Outer View
Inner View
Leave the slide cover in place if you route cables through the bottom
and then through a hole on the ceiling or wall.
RJ-45 Socket
Side View
Release tab
Slide cover
DI+ DI-
Max. is 40V.
Digital input
Lens
Tilt adjustment
screw
Reset button
Screw slot
MicroSD/SDHC
card slot
LEDs
