Vivotek FD8166 User Manual

VIVOTEK
118 - User's Manual
URL Command Document for All SeriesFD8166
3. General CGI URL Syntax and Parameters
When the CGI request includes internal camera parameters, these parameters must be written exactly
as they are named in the camera or video server. The CGIs are organized in functionally-related
directories under the cgi-bin directory. The file extension .cgi is required.
Syntax:
http://<servername>/cgi-bin/<subdir>[/<subdir>...]/<cgi>.<ext>
[?<parameter>=<value>[&<parameter>=<value>...]]
Example: Set digital output #1 to active
http://mywebserver/cgi-bin/dido/setdo.cgi?do1=1

Vivotek FD8166 Specifications

General

Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	-
Video formats supported	H.264, M-JPEG
Supported graphics resolutions	1920 x 1080 (HD 1080)
Pan range	0 - 45 °
White balance	Auto
Tilt angle range	33 - 90 °
Angle of rotation	360 °
Camera shutter type	Electronic
Camera shutter speed	1/32000 s
Minimum illumination	0.18 lx
Sensor type	CMOS
Optical sensor size	1/2.7 \
Optical zoom	48 x
Fixed focal length	6 mm
Video motion detection	Yes
Flash memory	16 MB
Compatible memory cards	microSD (TransFlash), SDHC
LED type	IR
Number of illumination LEDs	50
Certification	CE, C-Tick, LVD, VCCI
Placement supported	Indoor
Connectivity technology	Wired
Form factor	Dome
Mounting type	Ceiling
Product color	White
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
Signal-to-Noise Ratio (SNR)	53 dB
Wi-Fi	No
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X
Power source type	PoE
Power consumption (typical)	2.9 W
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Width	90 mm
Height	50 mm
Weight	144 g
