144 - User's Manual
Display
The Display window allows users to tune the image display options:
1. Video name: the video name is displayed on the title bar that is displayed on each
view cell. The screen shot below shows a name as "Speed dome."
2. Video name and timestamp: Default is enabled. If enabled, the video name and
time is displayed on the view cell.
3. Power line frequency: Depending on power line frequency of your country, select
a matching option, NTSC 60Hz or PAL 50Hz, to avoid image ickering due to
unmatched electricity.
4. Video orientation: select these options if the image from camera needs to be
vertically or horizontally ipped.
5. Click Restore to poll for the original settings or click the Apply button to nish the
process.
5-1-3. Settings - Camera > Image

Vivotek ND9541 Specifications

General

Maximum resolution	1920 x 1080 pixels
Alarm input channels	8
Video input channels	32 channels
Alarm output channels	4
Audio formats supported	G.711, G.726
On Screen Display (OSD)	Yes
Video formats supported	H.264, H.265, M-JPEG
Operating system installed	Embedded LINUX
RAID levels	0, 1, 5
HDD capacity	- GB
Maximum storage capacity	32 TB
Number of HDDs installed	-
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	IPv4, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, SMTP, FTP, DHCP, NTP, DNS, DDNS, IP Filter
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Certification	CE, LVD, FCC, VCCI, UL
Product color	Black

Weight and Dimensions

Depth	44.5 mm
Width	430 mm
Height	400 mm
Weight	3870 g
