172 - User's Manual
Primary DNS: The primary domain name server that translates hostnames into IP addresses.
Secondary DNS: Secondary domain name server that backups the Primary DNS.
When nished with the network settings, click on the Apply button.
Settings - Network - IP
DHCP: Default is selected, the server obtains an available dynamic IP address assigned by the DHCP
server each time the system is connected to the LAN.
Manual setup: Select this option to manually assign a static IP address to the Network Camera.
Enter the Static IP, Subnet mask, Default router, and Primary DNS provided by your ISP.
Subnet mask: This is used to determine if the destination is in the same subnet. The default value is
“255.255.255.0”.
Default router: This is the gateway used to forward frames to destinations in a different subnet. Invalid
router setting will fail the transmission to destinations in different subnet.

Vivotek ND9541 Specifications

General

Maximum resolution	1920 x 1080 pixels
Alarm input channels	8
Video input channels	32 channels
Alarm output channels	4
Audio formats supported	G.711, G.726
On Screen Display (OSD)	Yes
Video formats supported	H.264, H.265, M-JPEG
Operating system installed	Embedded LINUX
RAID levels	0, 1, 5
HDD capacity	- GB
Maximum storage capacity	32 TB
Number of HDDs installed	-
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	IPv4, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, SMTP, FTP, DHCP, NTP, DNS, DDNS, IP Filter
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Certification	CE, LVD, FCC, VCCI, UL
Product color	Black

Weight and Dimensions

Depth	44.5 mm
Width	430 mm
Height	400 mm
Weight	3870 g
