Vivotek ND9541 User Manual

VIVOTEK - Built with Reliability
10 - User's Manual
IMPORTANT:
It is important to leave a clearance of 25cm behind the chassis. The clearance is required to
ensure an adequate airow through the chassis to ventilate heat.
25cm
SATA hard disk(s) are user-supplied. The network video recorder can readily accommodate
most of the off-the-shelf SATA hard drives.
Hardware Installation
2
To ensure normal operation, maintain ambient airow. Do not block the airow around chassis
such as placing the system in a closed cabinet.
1. Use a screwdriver to loosen the retention screw on the sides of the chassis. Slide the top
cover back, and then remove the top cover.
NOTE:
You can also use the Reset button to restore system defaults. Press and hold down the button
for longer than 5 seconds. The system should start restoring defaults.
1

Vivotek ND9541 Specifications

General

Maximum resolution	1920 x 1080 pixels
Alarm input channels	8
Video input channels	32 channels
Alarm output channels	4
Audio formats supported	G.711, G.726
On Screen Display (OSD)	Yes
Video formats supported	H.264, H.265, M-JPEG
Operating system installed	Embedded LINUX
RAID levels	0, 1, 5
HDD capacity	- GB
Maximum storage capacity	32 TB
Number of HDDs installed	-
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	IPv4, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, SMTP, FTP, DHCP, NTP, DNS, DDNS, IP Filter
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Certification	CE, LVD, FCC, VCCI, UL
Product color	Black

Weight and Dimensions

Depth	44.5 mm
Width	430 mm
Height	400 mm
Weight	3870 g
