22 - User's Manual
If you connect the NVR to a PoE port of the AW-FED series PoE switch, make sure you turn off
the PoE output on that specic port using the onboard DIP switch. Otherwise, the high power
output can damage the LAN port on NVR.
WARNING:
ON
1 2 3 4 5 6 7 8
PoE cameras
NVR
AW-FED PoE switch
PoE ON/OFF switch
