ILLUSTRATED PARTS LIST FOR SYSTEM 9014 - 1996-1999 GMC CK2500, CK3500 &
HD3500 454 W/WOAC
DOCUMENT19307
ITEM QTY UNIT P/N DESCRIPTION
1 EA 1 1225 AIR COMPRESSOR
2 EA 1 2035 CLUTCH ASSEMBLY 6 GROOVE
3 EA 1 50060 1/2 NPT X 1/2 SAE CONNECTOR
4 EA 1 35363 TEMPERATURE PROBE
5 EA 1 92103 FILTER BLANK PLATE FITTING
6 EA 1 58045 3/4 ID VITON O RING
7 EA 1 92104 FILTER BLANK PLATE
8 EA 1 58002 2 3/8 ID VITON O RING
9 EA 1 92091 1/8 NPT (MODIFIED) SCAVANGE ORIFICE
10 EA 1 58004 3 1/8 ID VITON O RING
11 EA 1 50020 1/8 NPT X 1/4 POLYTUBE FITTING 90 DEG ELBOW
12 EA 1 92094 INLET CONTROL VALVE
13 EA 1 36037 PAPER FILTER ELEMENT
14 EA 1 36045 FILTER COVER
15 EA 1 15221 1/4 NC NUT
16 EA 1 15374 1/4 NC X 3 THREADED ROD
17 EA 1 15209 1/4 NC NYLOCK NUT
18 EA 1 50105 1/4 NPT X 1/4 POLYTUBE FITTING
19 EA 1 36046 REGULATOR VALVE
20 EA 1 43028 1/4 X 1/4 NPT CLOSE NIPPLE
21 EA 1 36058 REGULATOR/PTX MOUNT BLOCK
22 EA 1 36053 SILENCING REED
23 EA 2 15179 1/4 NC X 1 1/2 BOLT
24 EA 1 17055BLK 1/4 POLYTUBE 6" LONG
25 EA 1 50012 1/8 NPT X 1/4 POLYTUBE CONNECTOR
26 EA 1 50056 1/8 NPT TEE (BRASS)
27 EA 1 50020 1/8 NPT X 1/4 POLYTUBE FITTING 90 DEG ELBOW
28 EA 1 1/2 17055RED 1/4 POLYTUBE 8 1/2" LONG
29 EA 1 5039 THROTTLE CONTROLLER
30 EA 1 12203 THROTTLE CONTROL MOUNT BRACKET
31 EA 3 15427 8MM X 60 1.25 SCHS BOLTS
32 EA 2 15457 1/4 NC X 5/8 HHCS BOLTS
33 EA 1 14084 3/4 OD X 1/4 THICK SPACER
34 EA 1 92156 1/8 X 1/8 NPT (MODIFIED) ORIFICE FITTING
35 EA 1 50063 1/8 NPT X 1/4 SAE FITTING
36 EA 2 15209 1/4 NC NYLOCK NUT
37 EA 1 32070/15405 NIPPLE AND 8/32 X 1/4 SHCS
38 EA 1 32058 BRASS PULL NIPPLE
39 EA 1 15335 #10 NYLON WASHER
40 EA 1 12204 THROTTLE PULL BRACKET
To Next Page
