ILLUSTRATED PARTS LIST FOR SYSTEM 9014 - 1996-1999 GMC CK2500, CK3500 &
HD3500 454 W/WOAC
ITEM QTY UNIT P/N DESCRIPTION
41 EA 1 50063 HITCH PIN CLIP
42 EA 1 17313 1/4 HT X 72 1/2" PRESSURE CONTROL LINE
43 EA 1 17316 1/2 X 31 1/2 OIL RETURN LINE
44 EA 1 17314 5/16 X 77 1/2 SCAVENGE LINE
45 EA 1 17311 3/4 X 46 1/2 AIR HOSE
46 EA 1 17312 1/2 X 13 OIL RETURN LINE
47 EA 1 17315 1/2 X 71 1/2 OIL RETURN LINE
48 EA 1 17326 HOSE CONNECTOR TO ENGINE
49 EA 1 12183 COOLER MOUNTING BRACKET
50 EA 1 17116 HOSE LOW ER RA D TO REDUCER
51 EA 1 32091 REDUCER
52 EA 1 17243 HOSE CONNECTOR
53 EA 1 17319 HOSE COOLER (UPPER) TO CONNECTOR
54 EA 6 22026 HOSE CLAMP HS 28
54A EA 2 22062 HOSE CLAMP HS 24
55 EA 1 17117 HOSE COOLER (LOWER) TO REDUCER
56 EA 1 92135 COOLER ASSEMBLY
56A EA 1 49047 1/2 SAE MALE 90 DEG TO 1/2 SAE FEMALE SW
57 EA 1 17318 HOSE 90 DEGREE ELBOW
58 EA 1 17317 TOP RADIATOR TUBE
59 EA 1 17322 HOSE RE DUCING
60 EA 1 16221 BELT (5060670)
61 EA 1 34041 FAN SPACER
62 EA 1 12200 POWER STEERING PUMP SUPPORT BRACKET
63 EA 1 15161 1/2 NC X 1/14 FLANGE LOCK BOLT
64 EA 1 14051 IDLER BOLT SPACER
65 EA 1 13008 IDLER 6 RIB
66 EA 1 14148 TENSIONER SPACER
67 EA 1 13007 BACK IDLER
68 EA 1 26106 TENSIONER
69 EA 1 11125 VR7000 BRACKET
70 EA 1 50075 1/2 NPT X 1/2 SAE 45 DEGREE ELBOW
71 EA 1 45089 REMOTE FILTER ADAPTOR
72 EA 1 50074 1/2 NPT X 1/2 SAE 90 DEGREE ELBOW
73 EA 1 92039 OIL FILTER
74 EA 3 15028 1/4 NC X 3/4 HHCS BOLTS
75 EA 1 15044 3/8 SAE WASHER
76 EA 1 15138 10 MM 1.5 NYLOCK
77 EA 4 15454 COUPLING FASTENERS (MEDIUM)
78 EA 2 22101 TOP FRAME CLAMP
79 EA 4 15190 3/8 NC X 6" HHCS BOLTS
To Next Page
