ILLUSTRATED PARTS LIST FOR SYSTEM 9014 - 1996-1999 GMC CK2500, CK3500 &
HD3500 454 W/WOAC
49
DOCUMENT19300
ITEM QTY UNIT P/N DESCRIPTION
80 EA 8 15049 3/8 NC X 3/4 FLANGE LOCK B OLTS
81 EA 2 22093 BOTTOM FRAME CLAMP
82 EA 2 22092 TANK CRADLE
83 EA 2 22095 TANK CABLE
84 EA 1 18121 CRANK PULLEY
85 EA 3 15044 3/8 SAE PLAIN WASHERS
86 EA 3 15188 3/8 NF X 3 1/2 HHCS BOLTS
87 EA 1 15091 1/2 NF X 3 HHCS BOLT
88 EA 1 36055 FILTER SCREEN
89 EA 1 50064 1/8 NPT X 1/4 S AE 90 DEGREE ELBOW
90 EA 1 50082 1/8 NPT X 5/16 SAE STRAIGHT CONNECTOR
91 EA 1 92134 MAIN TANK
92 EA 1 49045 #8 ORB HEX SOCKET PLUG
93 EA 1 50060 1/2 NPT X 1/2 S AE CONNECTOR (BRASS )
94 EA 1 12202 ROCK GUARD
95 EA 1 49033 3/4 NPT X 3/4 JIC (37 DEGREE) CONNECTOR
96 EA 1 49036 3/4 JIC 45 DEGREE ELBOW (SWIVEL)
97 EA 1 15385 RETAINING RING
98 EA 1 32033 SIGHT GLASS WINDOW
99 EA 1 58008 1 15/16 ID VITON O RING
100 EA 1 36036 COALESCING ELEMENT
101 EA 1 58007 4 1/2 ID VITON O RING
102 EA 1 32107 DISCHARGE CAP
103 EA 1 35388 CONTROL BOX
104 EA 1 12184 SKID PLATE
105 EA 1 35391 INTERFACE CABLE
106 EA 1 35518 DRIVE DISABLE CIRCUIT
