If there is a malfunction in the airbag system,
the airbag will probably not deploy properly, will
not deploy at all or will deploy unexpectedly,
which could result in serious injury.
or deadly.
•
Have the airbag system checked immediately
by a specialist workshop.
•
Never use a child seat on the front passenger
seat. If one is fitted,
remove it! The front passenger frontal airbag
could be triggered in the event of an accident,
even in the event of an accident.
being out of order.
Control Witness
Please note at the beginning of this chapter
on
page 34.
Fig. 26 On the centre console: control lamp (schematic
representation) for deactivation of the front passenger
frontal airbag.
Fig. 27 On the centre console: control lamp
(schematic representation) for activation of the front
passenger airbag.
When the ignition is switched on, the yellow
indicator light in the instrument cluster
display comes on briefly as a function check
and goes out after a few seconds.
The front passenger frontal airbag
is deactivated. The yellow indicator
light in the centre console is
illuminated.
turns on and stays on.
The front passenger frontal airbag is
activated. The yellow indicator light in
the centre console goes out
automatically.
The vehicle is only activated automatically
after approx. 60 seconds after the ignition
has been switched on or after the front
passenger frontal airbag has been activated
using the key switch.
If the yellow PASSEN- GER AIR BAG indicator light
in the centre console does not remain lit
even when the front passenger airbag is
deactivated, the airbag will not be
deactivated.
If the warning lightis on or comes on together with
the yellowwarning light onthe instrument
panel display, there may be a malfunction in the
airbag system → .
Problems and solutions
Please note at the beginning of this chapter on
page 34.
Failure of the airbag system or of the
belt
pre-tensioners
The yellow indicator light comes on and stays on.
In addition, a message may be shown on the
instrument panel display.
A malfunction of at least one airbag or belt
pretensioner has been detected.
1.
Have the airbag and seatbelt pretensioner
system checked by a specialist workshop.
Airbag system or belt pretensioner system
deactivated with a diag-
nosis
After switching on the ignition, the yellow
indicator light comes on for approx. 4 seconds
and then flashes for approx. 12 seconds. In
addition, a message may be shown in the
instrument cluster display.
At least one airbag or belt pretensioner has been
deactivated by diagnostic equipment.
1.
Have a specialist workshop check whether the
airbag or seatbelt pretensioner system should
remain de-activated.
Front passenger frontal airbag
deactivated
The yellow indicator lamp indicating that the front
passenger air bag is deactivated comes on and
stays on.
The front passenger frontal airbag has been deactivated.
