28 - Chain tensioner
29 - 20 Nm
30 - 10 Nm +
1
/
4
turn (90°) further
❑ Renew.
31 - Chain sprocket
3.2 Removing and installing oil pump (for
balancer shaft module with chain drive)
Special tools and workshop equipment required
♦ Torque wrench (5…50 Nm) -V.A.G 1331-
♦ Locking pin -T10115-
♦ Used oil collection and extraction unit -V.A.G 1782-
Removing
– Position crankshaft at TDC for cylinder No. 1.
– Remove toothed belt ⇒ page 51 .
– Drain engine oil.
– Remove sump ⇒ page 117 .
– Remove sealing flange ⇒ page 35 .
Golf 2004 ➤ , Golf Plus 2005 ➤ , Passat 2006 ➤ , Touran 2003 ➤
4-cylinder diesel engine (2.0 l engine, 4 valve) - Edition 02.2011
3. Parts of lubrication system (Passat) 95
