– Now rotate crankshaft in direction of rotation to TDC and lock
crankshaft using crankshaft stop -T10050 bzw. T10100- .
Further installation is carried out in the reverse order. In the proc‐
ess, note the following:
– Install and tension toothed belt ⇒ page 51 .
– Install rocker arm shaft ⇒ page 81 .
– Install cylinder head cover ⇒ page 49 .
– Install oil supply line ⇒ page 123 .
– Install poly V-belt ⇒ page 16 .
– Fill with coolant ⇒ page 134 .
– Carry out road test and read fault memories ⇒ Vehicle diag‐
nostic tester.
1.5 Checking compression
A compression test is currently only possible on engines with pie‐
zo unit injectors ⇒ Vehicle diagnostic tester.
