– Fit adapter ring (colour marked „longer“ stud -arrow- faces 12
o'clock)
– Fit special wrench -T10310- on adapter ring and lock it by
turning key through 90° (
1
/
4
turn) in opposite
-direction of arrow-.
Note
When adapter ring is installed correctly the colour marked „short‐
er“ stud faces 12 o'clock)
– Fit central connector to cylinder head and lock in position.
– Install cylinder head cover ⇒ page 49 .
– Fit engine cover.
1.6 Assembly overview - unit injector
♦ Observe rules for cleanliness ⇒ page 243 .
♦ Always renew O-rings and securing bolts.
Golf 2004 ➤ , Golf Plus 2005 ➤ , Passat 2006 ➤ , Touran 2003 ➤
4-cylinder diesel engine (2.0 l engine, 4 valve) - Edition 02.2011
1. Diesel direct injection system 249
