32
3. DESCRIPTION OF INDIVIDUAL PARTS (see fold-out page)
1 Rotary switch for setting the measuring functions
2 Light button for torch function
3 MODE button for switching the measuring functions
4 Display (LCD) with function and measuring unit display
A Battery change display
B Prex with negative measuring values
C Indicator for direct (DC) or alternating current (AC)
D Indicator for automatic range selection (Auto-Range)
E Digital measuring value display (4000 digits)
F Diode test symbol
G Symbol for the acoustic continuity check
H Display of the measuring unit
5 NCV sensor (non-contact voltage detector)
6 Illuminated NCV display (NVC = non-contact voltage detector)
7 LED torch
8 Rear plug-in device for measuring leads
9 Button for frequency and duty cycle measuring function
10 Battery compartment
11 Grip section marking on the test prods
12 Measuring contact with plug in CAT III/CAT IV covering
