38
7. SCOPE OF DELIVERY
• Multimeter with permanently attached measuring leads
• 2 Cover plugs for the test prods
• 2 AAA batteries
• Operating instructions
8. INITIAL OPERATION
Prior to working with the measuring device, you have to insert the enclosed batteries.
Insert the batteries as described in the chapter „Cleaning and Maintenance“.
Rotary switch
The individual measuring functions can be set via the rotary switch. If
the rotary switch is set to „OFF“, the measuring device is switched off.
Always turn the measuring device off when it is not in use.
Attaching the test prods
Attach the test prods to the rear of the device’s
housing when it is not in use (protection during
transport).
You can also attach the measuring leads in a way
that allows measurements with one hand only.
Slide the two test prods into the rear holder as
shown on the diagram.
