VOLTCRAFT VC-20 - Page 52

52
Resistance, overload protection 600 V
Range Accuracy Resolution
400 Ω ±(1.2% + 7dgt) 0.1 Ω
4 KΩ
±(1.5% + 5dgt)
1 Ω
40 KΩ 10 Ω
400 KΩ 100 Ω
4 MΩ ±(5% + 5dgt) 1 KΩ
40 MΩ ±(10% + 5dgt) 10 KΩ
Capacity
Range Accuracy Resolution
4 nF ±(5.5% + 0.6 nF) 0.001 nF
40 nF
±(3.5% + 6dgt)
0.01 nF
400 nF 0.1 nF
4 µF
±(5% + 6dgt)
0.001 µF
40 µF 0.01 µF
200 µF ±(10% + 5dgt) 0.1 µF
Frequency
Range Accuracy Resolution
10 Hz
±(2% + 5dgt)
0.001 Hz
100 Hz 0.01 Hz
1000 Hz 0.1 Hz
10 KHz 1 Hz
