52
Frequency "Hz" (electronic)
Range Resolution Accuracy
99.99 Hz 0.01 Hz
±(0.1% + 5)
999.9 Hz 0.1 Hz
9.999 kHz 0.001 kHz
99.99 kHz 0.01 kHz
999.9 kHz 0.1 kHz
1.000 MHz 0.001 MHz
Signal level:
≤100kHz:100mVrms-20Vrms
>100 kHz to 1 MHz: 200 mVrms – 20 Vrms
Pulse ratio "%"
Range Resolution Accuracy
0.1 – 99.9 % 0.1 % Notspecied
Frequencyrange:≤100kHz
Display of the positive half-wave in %
Diode test
Test voltage Resolution
approx. 3.6 V 0.001 V
Overload protection: 600 V
The output current is calculated according to the following formula:
Current = test voltage / resistance
The resistance results from the total of internal PTC (1.5 kOhm) and the resistance of the tested diode
Acoustic continuity tester
Test voltage Resolution
approx. 3 V 0.1Ω
Overloadprotection:600V,measurementrangemax.400Ω;
Permanentsound<30Ω,nosound>60Ω,undenedrange>30to<60Ω
The output current is calculated according to the following formula:
Current = test voltage / resistance
The resistance results from the total of internal PTC (1.5 kOhm) and measured resistance section
