Volvo IPS950 - Page 60

Lamination of Hull Inserts
Lamination layers
Layer no. Mats Total density
g/m
2
(oz/yd
2
)
Lamination thickness
mm (in.)
1 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
2 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
3 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
4 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
5 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
6 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
7 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
8 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
9 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
10 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
11 E-BXM (+45°/-45°) 1075 (31.7) 1,4 (0.055)
12 E-BXM (+45°/-45°) 1075 (31.7) 1,4 (0.055)
13 E-BXM (+45°/-45°) 1075 (31.7) 1,4 (0.055)
14 E-BXM (+45°/-45°) 1075 (31.7) 1,4 (0.055)
15 E-BXM (+45°/-45°) 1075 (31.7) 1,4 (0.055)
16 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
17 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
18 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
19 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
20 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
21 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
22 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
23 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
24 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
25 E-LTM (0°/90°) 1075 (31.7) 0,9 (0.035)
Final lamination requirements:
≥ 25 ≥ 26 875 (792.8) ≥ 25 (1)
Installation, Volvo Penta IPS
58 47704162 10-2014 © AB VOLVO PENTA
