2. Connecting the TV (and VCR)
Vu+ provides a variety of audio/video connection methods.
A. Connecting TV via HDMI cable
For the sake of the best picture quality, especially for digital TV, HDMI connection is recommended.
Most HDTVs have HDMI connectors to ensure the highest picture quality. In the rear panel of Vu+
one HDMI connector is available for this purpose. Connect your TV to Vu+ using a HDMI cable as
follows.
HDMI
00
mA
LNB2
INPUT
S/
PDIF
V
IDE
O
Y
P
b
P
r
L
R
AUDIO
C
OMPONEN
T
TV
SC
ART
HDMI
HDMI
E
t
h
ernet
E-
S
AT
A
V
C
R
SC
ART
HDMI
B. Connecting TV via Component Cable
The secondly recommend TV connection for digital TV is via component cable (YPbPr). However,
unlike the HDMI connection which delivers audio and video signal at the same time, YPbPr
connection requires additional audio connection either via RCA cable (Stereo L/R) or S/PDIF as
follows.
LNB2
INPUT
S/
PDI
F
VIDE
O
Y
Pb
Pr
L
R
A
UDI
O
CO
MP
O
NEN
T
T
V
SC
AR
T
H
DMI
Ethernet
E
-
S
ATA
VC
R
SC
AR
T
S/PDIF
Y
Pb
Pr
YPbPr
S/PIF
Audio
L
R
or
NOTE : When you have an A/V receiver with S/PDIF digital audio input, this connection is
recommended to enjoy the best audio quality, especially for the Dolby Digital sound.
