| Technical specification
16
| Puranity TU+ VWR
Chapter 5
Depth Ø 388/ 15.28 inch Ø 384 / 15.12 inch
Weight with full capacity 37,5 kg / 82.57 lbs 71,5 kg / 157.66 lbs
Dimensions and weight 30L and 60L pure water tank
System 30L pure water tank 60L pure water tank
n388/15.28
6
0
6
n384/15.12
9
2
0
/
3
6
.
2
2
Water connections
Feedwater tubing Tube 1/4“ outer diameter
Concentrate tubing Tube 1/4“ outer diameter
Tank Flow tubing (only Puranity TU 12+)
Tank back flow tubing (only Puranity TU 12+)
Tube 1/4“ outer diameter
Tank overflow tubing (only Puranity TU 3+/6+) Tube 1/4“ outer diameter
Dispenser back flow tubing
Dispenser flow tubing
Tube 1/4“ outer diameter
Tube jumper Tube 1/4“ outer diameter
Front outlet ball valve Tube 1/4“ outer diameter
Electrical connections
Input voltage AC 100 – 240 V, 50 – 60 Hz, 5 – 3.8 A
Output voltage DC 24 V, 3.8 A
System connection DC 24 V, 80 W
Serial Interface RS232
Potential free contact maximum 30V, 2A
Protection class Class II (external SMPS certified as Class I)
