VWR Puranity TU3+ - Mounting the Power Pack (Voltage Supply)

| Installation
32
| Puranity TU+ VWR
Chapter 7
Mounting the power pack (voltage supply)
NOTE!
Whenever possible, mount the power pack on the wall to the left or right of the ultrapure water
system where it is freely accessible and not come in contact with water for get wet.
DANGER
Take caution to ensure that the suitable plug and the power cable do not get wet. Mount the
power pack with dry hands.
Risk of an electrical shock.
Step Action Figure
1 Remove the protective foil on the back
of the universal holder and from the
universal adapter and attach the
universal holder to the center of the
back of the main adapter.
2 Attach universal adapter to a smooth
wall surface with supplied screws or
with glue (not provided).
Universal
adapter
Universal holder
Universal foil
Mains
adapter
Universal adapter
Wall surface
