| Installation
26
|
Puranity TU+ VWR
Chapter 7
Bring your Puranity TU+ system into operation
NOTE!
After Installation all tubings have to be checked for their correct position on the
systems panel and that is no leakage after open the feedwater supply.
To avoid tripping, ensure that the tubings and wires do not lay over the floor.
Step Action Figure
1 Place the Puranity TU+ system at the
desired location (on the workbench,
under the workbench, or wall-mount).
A wall attachment kit is available for
wall-mounting (purchasing
separately).
See Section “Wall mounting” on page 31.
2 Remove the cover from the ultrapure
cartridge by pressing the snapper and
pull the cover off towards the front.
3 a. Locate the ultrapure
cartridge.
b. Place the ultrapure cartridge
in the rear section of the
system and insert the two
quick connectors into the
ultrapure cartridge. When
you hear an audible click
you can be sure that the
quick connectors have been
inserted correctly
NOTE!
The quick connectors are attached to
the system in such
a manner so as to prevent installing
the ultrapure
cartridge incorrectly.
