VWR Puranity TU+ | 33
Installation |
Chapter 7
3 a. Take the power supply unit
and press it with the
attached universal holder
onto the wall and then slide
it down (see red arrows).
b. Plug the power cable into
the power supply unit.
DANGER
Do not bring the
power pack in
contact with water.
Risk of an electrical shock.
NOTE!
The removable power cable must
always face downward
when the power supply unit has
been mounted.
4 Now, connect the power supply unit to
the 'Power supply' connection on the
right side of the Puranity TU 3+/6+ or
Puranity TU 12+ system. Next plug
the power supply to a grounded 100 -
240V, 50/60 Hz power outlet.
NOTE!
As soon as connect the power
supply unit to the power supply
connection of the system, the
display from the display control is
on. After 5 minutes the system is
going to be begin with producing
pure water.
5 The system is now ready for work.
Step Action Figure
