6
IVTM
Installation
34
Valve extension
Do
Do tight under permanently
existing pressure.
Use flexible valve extensions with tightening clamps (e.g. alligator) or WABCO
valve extensions 960 731 805 0 instead.
not use valve extensions made of plastic
not use plastic valve extensions. These will not remain
fig. 6-5: Twin wheels (outer wheel) fig. 6-6: Twin wheels (inner wheel)
6.2 Mounting the ECU n
ECU position on vehicle
ng to the following illustration.
nstall
the wireless connection to the
trailer is not shielded of by the coupling.
i bus / towing vehicle
Towing v
ehicle
The ECU plug must point to side (to the right or left) but not up or down.
– Choose a fitting position accordi
– If the vehicle is equipped with a low lying coupling for central axle trailer, i
the ECU on the right side of the vehicle, so that
fig. 6-7: Assembly at longitudinal beam
