10
TEBS E
Operation
174
Button
symbol
Function
Unloading level
Activation: Touch button.
Activate previous level: Touch button again.
TailGUARD
Activation: Engage reverse gear.
Deactivating (including deactivating the automatic braking function, visual and acoustic warning): Touch button.
Override deactivation: Disengage reverse gear.
Activation by button is not possible.
Road finisher brake
Activation: Touch button.
Disabling: Touch the button again or automatic if the vehicle speed is > 10 km/h.
Call up menu ‘Settings’: Touch the button > 2 seconds.
The braking pressure can be set in 0.1 bar steps with the +/- button (F2 & F5); Values between 0.5 and 6.5 bar
are possible.
The availability of the +/- functionality on buttons F2 and F5 is indicated by the upper part of the ring flashing in
green.
The actual situation is displayed when the function is switched on. The values for the TEBS E integrated pressure
sensor are shown and can be adjusted directly. The display is in the 1st and 2nd columns of the LED rows. The
1st column shows the whole-number pressure value while the 2nd column shows the decimal place.
Exiting menu ‘Settings’: Touch button > 2 seconds or if no button is touched > 5 seconds.
