OM 28Z3 US – Edition 2.0 * 28Z3b510.fm 5-3
Maintenance
Draining the fuel
Warning!
Fire and burn hazard. Draining fuel may ignite if it comes into contact with hot
engine parts or the exhaust system. Hot fuel may cause burns.
• Always wear protective equipment and safety glasses when working
with fuel.
• Never bleed the fuel system if the engine is hot.
Environment!
Use a suitable container to collect the fuel as it drains and dispose of it in an environmen-
tally friendly manner!
Filler inlet A (Fig. 103) for the fuel tank is located in the valve compartment, on the left in
driving direction.
Proceed as follows:
☞ Open filler inlet A
☞ Pump out the fuel with a suitable pump
➥ Collect the fuel in a suitable container
Stationary fuel pumps
General
Only refuel from stationary fuel pumps. Fuel from barrels or cans is usually dirty.
Even the smallest particles of dirt may cause
• Increased engine wear
• Malfunctions in the fuel system and
• Reduced effectiveness of the fuel filters
Refueling from barrels
If refueling from barrels cannot be avoided, note the following points (see fig. 114):
• Barrels must neither be rolled nor tilted before refueling
• Protect the suction pipe opening of the barrel pump with a fine-mesh screen
• Immerse the suction pipe into the barrel until there is 15 cm (6") of clearance from the
end of the pipe to the bottom of the barrel.
• Only fill the tank using refueling aids (funnels or filler pipes) with integral microfilter
• Keep all refueling containers clean at all times
Fig. 113: Fuel tank
A
wrong
right
Fig. 114: Refueling from a barrel
