6.14 Lift capacity table 28Z3, long stick option
All table indications in kg (lbs.) and horizontal position on firm ground without bucket.
If equipped with a bucket or other attachments, lift capacity or tilt load is reduced by bucket
or attachment dead weight.
Calculation basis: according to ISO 10567
The track excavator's lift capacity is restricted by the settings of the pressure limiting
valves and the hydraulic system's stabilising features.
Neither 75 % of the static tilt load nor 87 % of the hydraulic lift capacity is exceeded.
Fig. 143: Lift capacity table (model 28Z3)
A
3,5 m
(11’6")
3,0 m
(9’10")
2,5 m
(8’2")
B
3,0 m
(9’10")
*460
(1014=
405
(893)
--
*425
(937)
*425
(937)
--
2,0 m
(6’7")
*450
(992)
310
(683)
*450
(992)
380
(838)
*470
(1036)
*470
(1036)
--
1,0 m
(3’3")
*460
(1014)
285
(628)
*525
(1157)
365
(805)
*620
(1367)
455
(1003)
*800
(1764)
590
(1301)
0,0 m
(0’0")
*470
(1036)
295
(650)
*580
(1279)
350
(772)
*720
(1587)
430
(948)
*955
(2105)
555
(1224)
-1,0 m
(-3’3")
*480
(1058)
355
(783)
*475
(1047)
350
(772)
*650
(1433)
430
(948)
*855
(1885)
555
(1224)
max Admissible load on extended stick
A Reach from live ring center
B Load hook height
* Lift capacity limited by hydraulics
With the stabilizer blade in driving direction
Without the stabilizer blade, 90° to driving direction
