OM 28Z3 US – Edition 2.0 * 28Z3b330.fm 3-27
Operation
Weight adjustment
Important!
Adjust the seat suspension correctly to ensure a high level of ride comfort. Use the
lever to adjust the seat suspension.
Adjust the seat only without load!
Adjust the seat to the driver's weight as follows:
➥ Less spring action:
☞ Push the lever down.
➥ More spring action:
☞ Push the lever up.
Horizontal adjustment
☞ Sit in the seat.
☞ Pull lever 8 upward and at the same time, move the seat forward or backward.
☞ Sit in the seat.
☞ Pull handle 11 forward and, at the same time, lean back to push the backrest into the
required position.
☞ Release handle 11 and allow it to lock into place.
Fig. 25: Weight adjustment
B
A
Fig. 26: Horizontal seat adjustment
8
Fig. 27: Backrest adjustment
11
