OM 28Z3 US – Edition 2.0 * 28Z3b510.fm 5-7
Maintenance
Adding engine oil
NOTICE
Possibility of engine damage from too much oil or incorrect engine oil.
• Do not add engine oil above the MAX mark of oil dipstick 117/A
• Use only the specified engine oil
Environment!
Use a suitable container to collect the engine oil as it drains and dispose of it in an environ-
mentally friendly manner!
Filling up engine oil
☞ Proceed as follows:
• Clean the area around oil filler cap B with a lint-free cloth
• Open filler cap B
• Raise oil dipstick A slightly to allow any trapped air to escape
• Add engine oil
• Wait about 3 minutes until all the oil has run into the oil sump
• Check the oil level – see Checking the oil level on page 5-6
• Add oil if necessary and check the oil level again
• Close filler cap B
• Push oil dipstick A back in as far as possible
• Completely remove all oil spills from the engine
Fig. 117: Oil dipstick and oil filler cap
OIL
B
A
