3-20 OM 28Z3 US – Edition 2.0 * * 28Z3b330.fm
Operation
Stabilizer blade operation
Important!
Possible loss of machine control. Stabilizer blade lever is unprotected and can be
moved unintentionally.
• Avoid moving the stabilizer blade lever inadvertently.
NOTICE
Possibility of equipment damage. Lowering the stabilizer blade too deeply into
the ground can create a resistance – see Grading on page 3-75.
• Slightly raise the stabilizer blade
Important!
Check the position of the stabilizer blade before driving the machine.
Fig. 14: Stabilizer blade operation
2
1
Position Function
•1
Push forward Stabilizer blade is lowered
•2
Pull backward Stabilizer blade is raised
