DPU 130Le 8 Use and operation
Operator's manual
54
Closing protective hoods
Closing the front protective hood
f Grasp the front protective hood with both hands above the receiver unit and
close completely.
The protective hood is completely closed when it locks into place.
Closing rear protective hood
f Lift up the rear protective hood with the hood opener and close it completely.
The protective hood is completely closed when it locks into place.
Item Designation
1 Latch of front protective hood
2 Rear protective hood opener
NOTICE
Improper handling can cause damage to the machine.
f First close the front protective hood, then the rear protective hood.
f Both protective hoods must be completely closed during operation.
WARNING
A protective hood can cause pinching injuries during closing.
f Do not reach between the machine and the protective hood when closing
the protective hoods.
f First close the front protective hood, then the rear protective hood.
