BA ET18, 20, 24 en* 1.5 * et18_20_24b510.fm 5-37
Operation 5
Adjust the required oil flow with the rotary switch on the control lever base
on the left.
Actuating the Powertilt unit
Rotating the Powertilt unit to the left:
Push slide switch 23 on the left-hand control lever to the left.
Rotating the Powertilt unit to the right:
Push slide switch 23 on the left-hand control lever to the right.
Fig. 177Setting the oil flow
Fig. 178Actuating the Powertilt unit
23
Fig. 179Rotating the Powertilt unit
Rotation to
the left
Rotation to
the right
