BA ET18, 20, 24 en* 1.5 * et18_20_24i400.fm 4-13
Putting into operation 4
Fastening the seat belt
1. Insert buckle latch A into seat belt buckle B with an audible click.
2. Tighten seat belt C by pulling at its end.
Unfastening the seat belt
1. Press the red push button D on seat belt buckle B until the buckle latch
comes out.
2. Place seat belt C aside.
Longer/shorter seat belt adjustment
Longer seat belt adjustment
Hold buckle latch A at a right angle to the seat belt and pull the seat belt to
the required length.
Shorter seat belt adjustment
Pull the free end of the seat belt and shorten it to the required length.
Fig. 78Fastening the seat belt
A
B
C
Fig. 79Unfastening the seat belt
C
B
D
Fig. 80Longer/shorter seat belt adjustment
A
