Putting into operation 4
6. Mounting point for cabin/canopy: B (upper)/D (lower)
7. Tighten screws F (M12/10.9) and lock nuts on the left and right to 110
Nm (87 ft.lbs).
8. Install the mirrors in both positions E.
Fig. 93Lower mounting point
F
Fig. 94Upper mounting point on machine
B
Fig. 95Lower mounting point on machine
D
