Putting into operation 4
Designation See page
1 Cabin fuse box
9-9
2 Left storage compartment
--
3 Armrest (left)
4-22
4 Switch panel
4-32
5 Control lever on the left
5-19
6 Control lever base
4-54
7 Pedal for triple articulation boom (option)
5-32
8 Drive pedals
5-6
9 Drive levers
5-6
10 Boom swivel pedal
5-32
11 Multi-functional display (3.5" standard; 7" with optional reversing camera)
4-36; 4-21
12 Temperature control/automatic air conditioning (option)
4-32
13 Compartment for mobile phone
--
14 Control lever on the right
5-19
15 USB port (see Operator’s Manual for radio)
--
16 Speed range selection
5-3
17 Stabilizer-blade lever
5-24
18 Jog dial
4-32
19 Keypad
4-32
20 Right armrest
--
21 Switch panel, right side (option)
5-41
22 Throttle
5-1
23 Ignition lock
4-53
24 Radio (option – see operator’s manual for radio)
--
25 Seat belt
4-17
26 12 V power outlet
--
27 Storage compartment, right side
--
28 Rear storage compartment
--
29 Document box (option)
--
30 Operator seat
4-10; 4-13
31 Seat belt buckle
4-17
32 Drinks holder
--
