Foreword
Loading and transporting
30
BA RD24_RD28 en us 06
Loading chart
Diagram of the transport position
17757
Diagram of the centre of gravity specifications:
17758
Lashing variant 1
17759
Weight class [t] Lashing force LC (μ=0.6) [daN]
to 5.7 2000
Lashing variant 2
17760
Weight class [t] Lashing force LC (μ=0.6) [daN]
to 5.7 2000
