Sub Systems WM 130/170/270 Repair
wc_tx000382gb.fm 80
10.2 Fuel System Diagram
Ref Description Ref Description Ref Description
a Fuel flow f Float k Pilot air jet
b Needle valve g Main jet l Bypass
c Float h Main nozzle m Pilot outlet
d Float chamber i Choke valve
e Pilot jet j Main air jet
