WAGNER PS 3.20 User Manual

ProSpray 3.20 17
GB
Repairs at the unit
11.9 PS 3.20 connection diagram
With EMI lter
Pos. Description
1 Power cord
2 Power switch
3* EMI lter
4 Pressure switch
5 Circuit breaker
6 Motor
7 Capacitors
Without EMI lter
Pos. Description
1 Power cord
2 Power switch
3 Pressure switch
4 Circuit breaker
5 Motor
6 Capacitors
Pos. Description
a Black / brown
b Green
c White / blue
d Blue
e Green / yellow
f White
g Brown
h Red
i Brown
Pos. Description
a Black / brown
b Green
c White / blue
d Blue
e White
f Black
g Red
h Brown
a
a
d
e
f
g
g
g
g
i
g
h
h
h
f
f
f
f
b
c
1
3
2
4
7
6
5
a
a
d
e
f
f
f
h
f
g
g
g
e
e
e
e
b
c
1
2
3
6
5
4
