WAGNER PS 3.20 User Manual

ProSpray 3.20 5
GB
Description of unit
3.3 Legend for explanatory diagram PS 3.20
1 Spray gun
2 High-pressure hose
3 Return hose
4 Suction hose
5 Frame
6 Drip cup
7 Power cord
8 ON/OFF switch
9 Relief valve
Lever position vertical – PRIME ( k circulation)
  Leverpositionhorizontal–SPRAY(p)
10 Pressure control knob
11 Oil cup for EasyGlide (EasyGlide prevents increased wear of
the packings)
12 Pressure gauge
13 Pusher stem (if equipped)
10
3
4
5
6
7
1
2
13
9
8
11
12
3.4 Explanatory diagram PS 3.20

WAGNER PS 3.20 Specifications

General

Brand	WAGNER
Model	PS 3.20
Category	Paint Sprayer
Language	English
