Install wind vane
Push the wind vane onto the shaft on the top of the sensor, until it stop
moving further, as shown in gure 3. Tighten the set screw, with a Philips
screw driver(size PH0), until the wind van cannot be removed from the axle,
as shown in gure 4. Make sure the wind vane spin freely. The wind vane’s
movement has a small amount of friction, which is helpful in providing steady
wind direction measurements.
3 4
There are four alphabet letter of “N”, ”E”, ”S”and “W” around the wind
direction, representing for the direction of North, East, South and West.
Wind direction sensor has to be adjusted so that the directions on the sensor
are matching with your real location. Permanent wind direction error will be
installation. when the wind direction sensor is not positioned correctly during
installation.
