Charger Status LED
The LED on the front cover of your charger will indicate its status of the charger with an intuitive color
code.
READY
The charger remains in this state when it is not connected to a vehicle and ready to be used.
Vehicle battery is fully charged.
The transition between connecting the vehicle and start charging/discharging.
The transition between resuming the charge/discharge and start charging/
discharging.
The vehicle is not switched o or locked.
The charger is waiting for a better time to charge/discharge based on electricity
costs or the electricity distributor commands.
The vehicle has a pending, programmed schedule within the next 12 hours.
• Charge paused: the user has paused the charger through the app or the gesture.
• Schedule completed: the charger is waiting for the next charging action.
CONNECTED
The charger detects that it is connected to a vehicle. There are few situations where the
charger can remain in this state.
• Waiting for vehicle demand: this situation occurs when the vehicle is not willing to
charge although the charger is ready. This is due to one of the following situations:
LOCKED
(LED blinking) The charger is locked. Only an authorized user can unlock it. User authentication
can be done via RFID vehicled, Face Recognition, Wallbox app or myWallbox portal.
ERROR
The charger is in fault mode. Do not try to charge in this condition. Contact Wallbox
Service so they can advise you on this topic.
CHARGING
(LED blinking) The charging process has started and the vehicle is being recharged for the
next ride.
DISCHARGING
(LED blinking) The vehicle is being discharged and power is being generated to the electrical
grid, based on the V2G/V2H configuration.
