4.0 INFORMATION REGARDING HANDLING
AND TRANSPORT
2
FIL.SILOTOP_zero.--.M.A4.0722.EN Issue: A4
07.22
15
4.1 Type of packaging
The lter is supplied on a pallet, protected by a wooden crate.
The signs for safe lifting and handling are shown on all the packages.
Packaging materials must be disposed of or recycled in compliance with standards in force.
A) Fragile: indicates that the package has to be handled and lifted carefully to avoid
damage.
B) Centre of gravity: indicates the position of the gravity centre of the package.
C) Harness: indicates the correct harness position for lifting the package.
D) Stacking limit: indicates the maximum stacking load of the packages.
E) Weight: indicates the maximum weight of the package.
Kg
ø B A1 A B H
WEIGHT INCLUDING THE WOODEN CRATE
(KG)
SILAB14
837 914 1000 1100 1300
115
SILAB24 122
dimensions in mm
